Play. Discover. Progress.
The FP-40 gives you everything you need to play piano, and every reason to keep going. Combining expressive sound, authentic feel, and seamless integration with the Piano Sphere app, it creates a connected experience that extends far beyond the instrument. Designed for a new era of piano playing, the FP-40 helps you stay inspired, build confidence, and keep progressing through the music you love.
Sound GeneratorPiano SoundPiano RealityMax. Polyphony256TonesInternal Tones: 305
Tones accessible directly from the piano: 40
Tones accessible only from the Roland Piano App: 265KeyboardKeyboard88 keys (PHA-4 Standard Keyboard: with Escapement and Ivory Feel)Speaker SystemSpeakers(8 x 12 cm) x 2 (with Speaker Box)Rated Power Output12 W x 2HeadphonesHeadphonesPiano Reality Headphones AmbienceWi-FiWi-FiFP-40-BK, FP-40-BKB, FP-40-WH, FP-40-WHB:
-Standards
IEEE 802.11b/g/n, 2.4 GHz band
-Security
WPA3-PSK (AES)
WPA2-PSK (AES/TKIP)
WPA-PSK (AES/TKIP)
-Antenna
Internal typeBluetoothBluetoothBluetooth Ver. 5.4
Profile: A2DP (Classic Audio), BAP (LE Audio), GATT (MIDI over Bluetooth Low Energy)
CODEC: SBC, LC3Compatible Android / iOS Apps (Roland)Compatible Android / iOS Apps (Roland)FP-40-BK, FP-40-BKB, FP-40-WH, FP-40-WHB:
Piano Sphere
Roland Piano AppData PlaybackStandard MIDI FilesStandard MIDI Files (Format 0, 1)Audio File (requires a USB flash drive, supports USB flash drives of 32 GB or less)WAV: 44.1 kHz, 16-bit linear format
MP3: 44.1 kHz, 64 k--320 kbpsRecorderStandard MIDI FilesStandard MIDI Files (Format 0)
Song: 1
Part: 1
Recording capacity per song: approx. 500 KBInternal SongsInternal Songs4Tuning, VoicingTouch SensitivityKey Touch: 5 steps, fixed touchMaster Tuning415.3--466.2 Hz (adjustable in increments of 0.1 Hz)EffectsAmbience: 11 steps
Brilliance: 21 steps
Only for organ tones: Rotary Speaker EffectPiano Designer (Settings can be changed only from the Roland Piano App)Lid
String Resonance
Damper Resonance
Key Off Resonance
Cabinet Resonance
Single Note Tuning
Single Note Volume
Single Note Character
Temperament
Temperament KeyConvenient FunctionsConvenient FunctionsMetronome (adjustable Tempo/Beat/Downbeat/Volume/Tone)
Transpose (in semitones)
Dual
Split
Twin Piano
Speaker Switch (Auto, On, Off)
Auto OffOtherConnectorsDC In jack
Pedal1 (Damper) jacks: capable of continuous detection when optional pedal connected
Pedal2 (Damper, Sostenuto, Soft) jacks: capable when dedicated pedal board connected
Output (L/Mono, R) jacks: 1/4-inch phone type
USB Mobile/PC port: USB Type-C (R) (supports USB MIDI/Audio and provides power to USB PD (Power Delivery)–compatible smartphones)
USB Memory port: USB A
Phones/Headset jack: Stereo miniature phone typePower SupplyAC adaptorPower Consumption22 W (When using the included AC adaptor)
*Approximate power consumption when playing the piano at the center value of the volume: 5 W
*Power consumption when sound has not been played after power-on: 3 W
*Power consumption when in OFF mode (when the power automatically turns off): 0.1 WAccessoriesStartup Guide
List of operations
Leaflet: "Read Me First"
AC adaptor (PSB-7U）
Power cord
Music rest
Pedal switch (DP-2)
USB 2.0 Type-C (R) to Type-C (R) Cable (1.5 m)Option (sold separately)FP-40-BK, FP-40-BKB, FP-40-WH, FP-40-WHB:
Dedicated stand: KSF-40
Dedicated pedal board: KPD-70
Keyboard stand: KS-11Z, KS-13, KS-20X, KS-G8B
Damper pedal: DP series
Carrying Bag: CB-B88V2, SC-G76W3Size and WeightDimensionsWith music rest detached:
1,307 (W) x 332 (D) x 122 (H) mm
51-1/2 (W) x 13-1/8 (D) x 4-13/16 (H) inches
FP-40-BK, FP-40-BKB, FP-40-WH, FP-40-WHB:
With music rest, dedicated stand KSF-40, and dedicated pedal board KPD-70 attached:
1,307 (W) x 384 (D) x 949 (H) mm
51-1/2 (W) x 15-1/8 (D) x 37-3/8 (H) inchesWeightWith music rest attached:
14.0 kg
30 lbs 14 oz
FP-40-BK, FP-40-BKB, FP-40-WH, FP-40-WHB:
With music rest, dedicated stand KSF-40, and dedicated pedal board KPD-70 attached:
24.1 kg
53 lbs 3 oz
