Main Characteristics
● 12 channel inputs include: 6 microphone inputs, 6 stereo inputs, and 2 hybrid stereo inputs
(including 3.5 analog stereo, stereo Bluetooth, USB/OTG sound card, USB flash disk playback).
● 2 SUB group output channels, 2 AUX auxiliary outputs, 1 FX effect sending, 1 stereo main
output, 1 stereo monitor/headphone output, and 2 stereo digital outputs (USB/OTG sound card,
USB flash disk recording).
● The microphone input channel has independent gain control, low cut, phantom power, PEQ
equalization, compressor, feedback inhibition, left and right balance adjustment, AUX sending,
FX effect sending, SUB group and main output L/R sending switches.
● The stereo input channel has independent gain control, PEQ equalization, left and right balance
adjustment, AUX sending, FX effect sending, SUB group and main output L/R sending switches.
● The SUB group output channel has independent compressor, 7-section PEQ equalization, left
and right balance, mute, main output sending switch and mute, etc.
● The stereo main output channel has independent compressor, 7-section PEQ equalization and
mute, etc.
● The AUX output channel has independent compressor, 7-section PEQ equalization and mute, etc.
● The FX channel has independent professional stereo effect, independent sending bus (with
adjustable volume), 16 effect combinations to be selected, of which detailed parameters of each
effect can be set.
● All input channels are available for any customized channel copy parameter function.
● It is available for 9 complete scene preset storage and call functions, all parameters can be
imported and exported by USB flash disk.
● The panel is available for USB flash disk player for previous, next, play and pause, as well as
real-time stereo recording function.
● The built-in USB sound card is available for PC-connected real-time recording and play functions.
● It is available for high-quality stereo Bluetooth V5.0 input, and compatible with Bluetooth V4.2 and
V2.1+EDR, and input volume can be controlled.
● It has independent customized user password protection function, realizing safe and reliable
operation and management of system.
● 7-inch HD 800*480 display screen, 5 high-precision 100MM electric faders, 18-section LED
real-time volume display position realize volume management for all channels through page
turning buttons on the panel.
● The built-in dual-mode Bluetooth module is available for BLE control protocol, and volume control,
mute management and scene are switched through APP. The central control protocol can also be
managed and controlled through the Ethernet port
