Sound GeneratorPiano SoundPiano Reality ModelingMax. PolyphonyPiano: Limitless (solo playing using Grand Piano tones) Other: 256TonesTotal Available Tones: 54
Tones Accessible directly from the piano: 6 (Grand Piano: 2, E. Piano: 2, Harpsichord: 1, Organ: 1)
Tones Accessible from the Roland Piano App: 54
* For data playback: 270, Conforms to GM2KeyboardKeyboardPHA-50 Hybrid Keyboard (88 keys Hammer Action Keyboard)
with Escapement, Ebony/Ivory Feel, and High Precision SensingPedalsPedalsDamper (Progressive Damper Action Pedal, capable of continuous detection, Damper Modeling)
Soft (capable of continuous detection)
SostenutoSpeaker SystemSpeakers12 cm (4-3/4 inches) x 2
5 cm (2 inches) x 2Rated Power Output24 W x 2HeadphonesHeadphonesPiano Reality Headphones AmbienceCabinetCabinetMusic rest: Fixed angle
Keyboard cover: Folding typeTuning, VoicingTouch SensitivityKey Touch: 5 steps, fixed touchMaster Tuning415.3--466.2 Hz (adjustable in increments of 0.1 Hz)Temperament (Settings can be changed only through Roland Piano App.)10 types (Equal, Just Major, Just Minor, Pythagorean, Kirnberger I, Kirnberger II, Kirnberger III, Meantone, Werckmeister, Arabic), selectable temperament keyEffectsAmbience, BrilliancePiano Designer (Settings can be changed only through Roland Piano App.)Lid
Key Off Noise
Hammer Noise
Duplex Scale
Full Scale String Resonance
Damper Resonance
Key Off Resonance
Cabinet Resonance
Soundboard Type
Damper Modeling
Single Note Tuning
Single Note Volume
Single Note CharacterInternal SongsInternal Songs30Data PlaybackStandard MIDI FilesStandard MIDI Files (Format 0, 1)Audio File (requires a USB flash drive, only supports USB flash drives of 32GB and under)WAV: 44.1 kHz, 16-bit linear format
MP3: 44.1 kHz, 64 kbps--320 kbpsRecorderStandard MIDI FilesStandard MIDI Files (Format 0)
Song: 1
Part: 1
Recording capacity per song: approx. 500 KBBluetoothBluetoothBluetooth Ver. 5.0
Profile: A2DP (Audio), GATT (MIDI over Bluetooth Low Energy)
CODEC: SBC (Supports SCMS-T content protection)Compatible Android / iOS Apps (Roland)Compatible Android / iOS Apps (Roland)Roland Piano AppConvenient FunctionsConvenient FunctionsMetronome (adjustable Tempo/Beat/Downbeat/Volume)
Transpose (in semitones)
Auto OffOtherConnectorsDC In jack
USB Mobile/PC port: USB Type-C(R) (compatible with USB MIDI/Audio)
USB Memory port: USB A
Phones jack x 2: Stereo miniature phone type, Stereo 1/4-inch phone typePower SupplyAC adapterPower ConsumptionPower consumption: 17 W (when using the included AC adapter)
* Approximate power consumption when playing the piano at the center value of the volume: 8 W
* Power consumption when sound has not been played after power-on: 7 W
* Power consumption when in OFF mode (when the power automatically turns off): 0.3 WAccessoriesQuick Operations Guide
Leaflet Assembly
Leaflet "USING THE UNIT SAFELY"
Leaflet "Care and Maintenance of Wood Products"
AC adapter (PSB-14U)
Power cord
Headphone hook
Stabilizers
Dedicated pedal
Dedicated fixed-height benchSize: Piano with lid closedWidth1,396 mm
55 inchesDepth382 mm
15-1/16 inchesHeight783 mm
30-7/8 inchesSize: Piano with lid open (* Stabilizers mounted)Width1,396 mm
55 inchesDepth382 mm
15-1/16 inchesHeight910mm
35-7/8 inchesSize: PedalWidth292mm
11-1/2 inchesDepth216 mm
8-9/16 inchesHeight95mm
3-3/4 inchesSize: BenchWidth442 mm
17-7/16 inchesDepth302 mm
11-15/16 inchesHeight520 mm
20-1/2 inchesWeightPiano34.0 kg / 75 lbsPedal2.1 kg / 4 lbs 11 ozBench4.7 kg / 10 lbs 6 oz
